Câmera de rede bullet fixa de 2 MP - DS-2CD1021G0-I#BRASIL
- Imagens de alta qualidade com resolução de 2 MP
- Resistente à água e poeira (IP67)
- Fácil instalação com tecnologia Power over Ethernet (PoE)
Especificações Técnicas: Câmera: Sensor de Imagem: - 1/2.9" Progressive Scan CMOS.
Resolução Máxima: - 1920 × 1080.
Iluminação Mínima: - Color: 0.01 Lux @ (F2.2, AGC ON), B/W: 0 Lux with IR.
Tempo do Obturador: - 1/3 s to 1/100,000 s.
Dia e Noite: - IR cut filter.
Ajuste de Ângulo: - Pan: 0 to 360, tilt: 0 to 90, rotate: 0 to 360.
Lentes: Tipo de Lente: - Fixed focal lens, 2.8 and 4 mm optional.
Focal Length & FOV: - 2.8 mm, horizontal FOV 94, vertical FOV 51, diagonal FOV 112. - 4 mm, horizontal FOV 80, vertical FOV 44, diagonal FOV 94.
Montagem da Lente: - M12.
Iris Type: - Fixed.
Abertura: - F2.2.
DORI: - 2.8 mm: D: 48 m, O: 19 m, R: 9 m, I: 4 m. - 4 mm: D: 55 m, O: 22 m, R: 11 m, I: 5 m.
Luminador:
Tipo de Luz Suplementar: - IR.
Faixa de Luz Suplementar: - Up to 30 m.
Luz Complementar Inteligente: - Yes.
Vídeo: Convencional: - 50 Hz: 25 fps (1920 × 1080, 1280 × 720). - 60 Hz: 30 fps (1920 × 1080, 1280 × 720).
Subfluxo: - 50 Hz: 25 fps (640 × 480, 640 × 360). - 60 Hz: 30 fps (640 × 480, 640 × 360).
Compressão de Vídeo: - Main stream: H.265+/H.265/H.264+/H.264, - Sub-stream: H.265/H.264.
Taxa de Bits de Vídeo: - 32 Kbps to 8 Mbps.
Tipo H.264: - Baseline Profile, Main Profile, High Profile.
Tipo H.265: - Main Profile.
Controle da Taxa de Bits: - CBR, VBR.
Rede: Segurança: - Password protection, complicated password, watermark, basic and digest authentication for http, security audit log, host authentication (MAC address).
Visualização ao Vivo Simultânea: - Up to 6 channels.
API: - ISAPI, SDK.
Protocolos: - TCP/IP, ICMP, DHCP, DNS, http, RTP, RTSP, NTP, IGMP, UDP, QoS.
Usuário/Host: - Up to 32 users. - 3 user levels: administrator, operator, and user.
Client: - iVMS-4200.
Navegador da Web: - Plug-in required live view: IE 10, IE 11, - Local service: Chrome 57.0+, Firefox 52.0+.
Imagem: Ampla Faixa Dinâmica (WDR): - Digital WDR.
SNR: - = 52 dB.
Switch Dia/Noite: - Day, Night, Auto, Schedule.
Aprimoramento da Imagem: - BLC, HLC, 3D DNR.
Configurações de Imagem: - Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser.
Interface:
Ethernet Interface: - 1 RJ45 10 M/100 M self-adaptive Ethernet port.
Evento: Eventos Básicos: - Motion detection, exception.
Linkage: - Notify surveillance center.
Geral: Alimentação: - 12 VDC 25%, 0.41 A, max. 5 W, Ø5.5 mm coaxial power plug, reverse polarity protection, - PoE: IEEE 802.3af, Class 3, max. 6.5 W.
Material: - Plastic.
Dimensões: - 138.8 mm × 60.9 mm × 57.9 mm (5.5" × 2.4" × 2.3").
Dimensões do Pacote: - 163 mm × 75 mm × 75 mm (6.4" × 3.0" × 3.0").
Peso: Approx. 175 g (0.4 lb.).
Com Peso do Pacote: - Approx. 250 g (1.1 lb.).
Condições de Armazenamento: --30 C to 60 C (-22 F to 140 F). Humidity 95% or less (non-condensing).
Condições de Inicialização e Operação: - -30 C to 60 C (-22 F to 140 F). Humidity 95% or less (non-condensing).
Idioma: - English, Ukrainian.
Função Geral: - Heartbeat, anti-banding, mirror, password protection, password reset via email.
Aprovação: - EMC: - CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014.
Segurança: - CB: IEC 62368-1: 2014+A11, - CE-LVD: EN 62368-1: 2014/A11: 2017.
Ambiente: - CE-RoHS: 2011/65/EU, - WEEE: 2012/19/EU, - Reach: Regulation (EC) No 1907/2006.
Proteção: - IP67: IEC 60529-2013.
Camera Bullet de rede fixa 2 MP de resolução
Imagens de alta qualidade com resolução de 2 MP
Resistente à água e poeira (IP67)
Fácil instalação com tecnologia Power over Ethernet (PoE)
